MM-R2 2020A Microphone HQ. Low Noise Preamplifier Board With Gain Bass Treble Control

$15.00

Add to Wishlist

Availability:

5 in stock

Categories: Pre-Amplifiers, Input & Microphone Stage

Description

Description

MM-R2 2020A

Dynamic Microphone High Quality Low Noise Preamplifier Board With Gain Bass Treble Control

High Quality FR-4 + components Assembled

On board Dual Voltage Stabilizer

With Low Noise OP AMP TL074

We Use ONLY Original Genuine Parts

Input Impedance: 560Ohm

Input Gain: 55db

Frequency Response: 20-20k Hz (+0, -3 dB)

Output Impedance: 100Ohm

Tone Controls: Baxandal Two-band, shelving

Bass: +/- 12db

Treble: +/- 12db

Working Voltage: Dual +/-12-24 Vdc Recommended 18VDC

**PCB Size: 68mm*46mm double-sided HAL,FR4 1.6MM**

Potentiometer Gap: 25mm

Applications: DIY Home/ DJ Mixers
