Description
M-PHM56
High Quality Amazing Sound Headphones Amplifier.
High Quality Amplifier for DIY
Low Noise High Quality OP Amp Driver
Work with both AC/DC Power Supply
Small size PCB
I.C Can be SMT or T.H (We send Randomly Type)
Output Power: Up to 5Vrms with 32 Ohm Headphones
3 Order option:
1.Assembled board with 3.5mm Headphones Connector
2.Assembled board with 3 Pin Molex Connector
3. DIY KIT PCB + Parts you need to place & solder
High quality and reliability FR4 1.6MM PCB
Working Voltage: Min. 2x6Vac to Max. 2x10Vac or 2x12Vdc to 2x15Vdc
Frequency Response: 15Hz-45,000Hz
Power Out: 400mW Both Ch. Drive 32 Ohm Headphones (3.6-5Vrms)
Input sensitivity: 1V 0dbv (To max. power drive)
PCB Size: 57mm*38mm double-sided HAL,FR4 1.6MM
